Configure Halo PSA Integration

Use this MSP staff workflow to connect Halo PSA and configure the data available to your portal. The Halo connection page keeps credentials, permissions, data selection, company and user matching, device import and configuration in its setup guide. The same tasks can open inside Launch Center. Company users do not administer this connection. MSPortal can also import HaloPSA native CSAT responses into the CSAT Dashboard, custom dashboard widgets, report blocks and CSV exports. See Import HaloPSA native CSAT for dashboards and reports.

On desktop, the Setup guide menu and the open task scroll independently beneath the connection header. On a phone, tap Setup guide to choose a step. See Move around a connection for desktop and phone previews.

Problems sync and reporting

Halo Problems use the same read:tickets API permission as tickets. Keep ticket sync enabled, link the client companies, and ensure the API agent can read the relevant teams, clients and ticket types. MSPortal uses Halo’s ITIL Ticket Type classification rather than assuming a ticket type is named “Problem”. The Problems sync includes recent activity and older unresolved records. Once synced, use the Problems source in Reports > New Report > Full Report or add the Problems block in Builder. See Halo Problems in QBRs for period and backlog meanings.

Prerequisites

Administrator access to your Halo PSA instance
Access to MSPortal.ai with integration management permissions. Ticket configuration also needs the Ticket Settings permission.
(Recommended) Custom MSPortal role and API-only agent created in Halo PSA

Part 1: Configure Halo PSA

Before connecting to MSPortal.ai, you need to create an API application in Halo PSA. Access depends on both the application’s permissions and the permissions of the agent it logs in as. See Halo’s API documentation.

Navigate to your Halo PSA instance and log in with an administrator account.

Create the MSPortal Role and Agent

Create the MSPortal role and API-only agent first. Follow Create Custom Halo PSA Role and API User, which lists every role permission and the teams the agent needs.

Open Integrations

Click Configuration in the navigation menu, then select Integrations > API.

Create API Application

Click View Applications
Create a new application named “MSPortal.ai”
Select Client ID and Secret (Services) as the authentication method
Save your Client ID and Client Secret. You need them in MSPortal.
Select your MSPortal API-only agent in Agent to Log in as

Make sure to save your Client ID and Client Secret immediately. The secret cannot be retrieved after creation.

Configure Permissions

Click Permissions and grant the application permissions listed in Link the Agent to Your API Application. read:customers and read:tickets are required. The rest turn on optional features.

Configure CORS Whitelist

Click Security
Add app.msportal.ai to the CORS whitelist
Click Submit to save

Project management permissions

Skip this section unless you will create or update Halo projects from MSPortal. Halo checks two things, the MSPortal.ai API application and the agent it logs in as. Application access cannot override a restriction on that agent.

Grant project and ticket access on the application

In Halo, go to Configuration > Integrations > API > View Applications, open MSPortal.ai and grant Project Read, Project Modify, Ticket Read and Ticket Modify.

Check the agent's permissions

Go to Configuration > Teams & Agents, open the MSPortal agent and its role, and confirm the access below. Halo projects are project records with child tickets and milestones, so project access alone does not cover child tickets, checklists or time.

Area	Read access	Create and update access
Projects	Project Read (`read:projects`) and agent access to the intended projects	Project Modify and agent permission to create and edit projects. Used to create a PSA project, update its status or mapped fields, and create or update its milestones.
Tickets	Ticket Read (`read:tickets`), including child project tickets	Ticket Modify and agent permission to create and edit the intended ticket types. Used to create project tickets and edit their details.
Actions and time	Read access to actions on the project and its child tickets	Agent access to add the relevant actions and record time. Used to post project ticket notes and time entries. Check action visibility, allowed outcomes and billing options on the agent.
Checklist (to-do) items	Read the child ticket and its checklist	Permission to add and update the ticket’s to-do items. Used to add checklist items and change completion.
Customers and agents	Customers Read (`read:customers`) and visibility of the relevant agents	Not needed. Read access fills company, contact and staff choices.
Ticket configuration and templates	Read the ticket types, statuses, priorities and project templates you use	Not needed for the source template. Creating work from a portal template uses the project and ticket permissions above.

Permission labels can vary by Halo version. Use your instance’s /apidoc to confirm the permissions for projects, tickets, actions, to-do items and templates.

Widen the agent's scope

Add the agent to every department and team the integration should cover. Allow the clients and ticket types it needs, including the project type and child ticket types. To cover all of them, turn on Allow All Clients and Allow All Ticket Types. Also check access to internal actions, project templates and the actions used for time entry.

Save and re-check

Save the application and agent. In MSPortal, open Settings > Integrations, open the Halo PSA connection, choose Permissions and click Re-check.

Test on a project

A green Projects result only confirms MSPortal can read projects. On a test project, create the project, edit a detail, complete a checklist item and add a note with time. If applying a template partly succeeds, check the records it created before you retry.

Project ticket status changes from the Kanban board or ticket details write back to Halo and need Ticket Modify. Project status changes from the portfolio Kanban write back to Halo too. Project, phase and ticket dates write back to Halo too, and a ticket’s start date cannot be changed from its details. See What writes back to your PSA. Project ticket owner and priority changes, checklist progress note editing and checklist deletion are not available for Halo in MSPortal. Do not grant blanket Delete or administrator access for these workflows. MSPortal-only projects and templates use MSPortal permissions only.

Part 2: Set up the connection in MSPortal

Open Settings > Integrations and choose Halo PSA from the Directory, or open its existing connection from Active. The Setup guide lists the tasks below. The connection header’s Docs button opens this documentation without changing your current task.

Connect

Enter API credentials

Field	Description
Halo URL	Your Halo PSA instance URL without a trailing slash (e.g., `https://yourhalo.haloservicedesk.com`)
Client ID	The Client ID from your Halo API application
Client Secret	The Client Secret from your Halo API application

Test the connection

Select Test connection and check the result. This tests the entered values; it does not save a new connection by itself.

If the connection fails, double-check your credentials and ensure the CORS whitelist includes app.msportal.ai.

Save

Select Save and continue to save a new connection and move to Permissions. In Launch Center, use its Continue control after a successful test to save and advance.

For an existing connection, a masked client secret means a value is stored. It does not represent a fresh test.

Permissions

MSPortal checks what your Halo API application is allowed to read, and shows the result for each area of data.

Review the results

The check runs automatically when you open this task. Each area of data is listed as granted, not permitted or could not verify.Areas marked Required must be granted before you can continue: Companies, Contacts and staff, Tickets, and Teams and statuses (statuses, priorities and ticket types). Without these the integration cannot function.Optional areas cover Assets, Opportunities, Product catalog, Invoices, Contracts, Projects, Time entries, Change management, and Satisfaction feedback.

Grant anything missing

Any area that is not permitted shows the exact Halo permission to grant, for example read:items for the product catalog.Open your MSPortal application under Configuration > Integrations > API > Applications, grant the permission (or the all scope), then come back and click Re-check. Tickets and statuses also depend on the API agent’s team membership.

Halo often refuses a scope-limited application at the token endpoint rather than per resource. If every area comes back unchecked with an authentication error, widen the application’s permissions rather than chasing individual areas.

Continue

You can continue with optional areas ungranted. Those syncs stay switched off and their toggles are locked in Choose data until you grant the permission and re-check.

Read the reported failure before changing the API role. A timeout, unavailable endpoint or unverified check is not automatically proof of a missing permission. These checks exercise read access; they do not prove that ticket creation, comments, warranty updates or other writes will succeed.

If a permission is removed later, MSPortal switches off the affected sync and notifies your integration admins rather than retrying against an endpoint it can no longer read.

Choose data

Choose what to sync from Halo PSA. Switches sit side by side in two groups, Core data and Extended data. Turning a switch on reveals its settings below that group, and turning it off hides them without clearing saved filters. Each switch and selector has an (i) beside its name: hover over, tap or focus it to read what the setting does. Switches and scope selectors save immediately; wait for the save result.

Option	Description
Sync Users	Sync user/contact data from Halo PSA
Sync Companies	Sync company/client data from Halo PSA
Enable Ticket Sync	Sync tickets from Halo PSA. Reveals Ticket Sync Scope.
Enable Opportunity Sync	Sync opportunities from Halo PSA. Reveals the Auto-import to Planner switch.
Enable Project Sync	Sync projects from Halo PSA. Use Exclude Project Types to skip projects of certain Halo ticket types.
Enable Invoice Sync	Sync invoices from Halo PSA. Reveals Hide invoice statuses.
Sync product catalog	Import the product and service catalog for quoting and budgets
Enable asset sync	Sync assets on a recurring schedule. Use Asset statuses to exclude to skip statuses. Excluding a status stops syncing those assets and keeps their devices. Inactive assets follow Devices from Halo assets.
Enable change management	Import Halo changes into the change calendar
Import satisfaction ratings	Import Halo satisfaction feedback. See Import HaloPSA native CSAT.
Warranty writeback	Write warranty data back to Halo assets when MSPortal resolves a device’s warranty. Appears when Enable asset sync is on. This is a vendor write; enable it only when you intend resolved warranty data to update Halo.

A toggle appears locked when the permission check found that your API application cannot read that data. Grant the permission named beside it in Halo, then select Re-check in Permissions to unlock it.

Ticket sync scope

Setting	Description
Teams to Sync	Select which Halo teams’ tickets to sync. Only tickets from selected teams appear in MSPortal.
Exclude Statuses	Select ticket statuses to exclude from sync (e.g., Closed, Cancelled)
Exclude Ticket Types	Select Halo ticket types to exclude, such as Alert. Leave it empty to allow all types.

Previously synchronized tickets of an excluded type are removed on the next sync, and changing ticket type exclusions requests a fresh ticket sync. Project type exclusions have their own scope. To restore a type, open the selector and uncheck it. Saved IDs missing from Halo’s catalog appear as Unknown ticket type (ID); you can uncheck these even while the catalog is loading or unavailable.

Halo ticket type exclusion selector with a checked unknown type that can be removed — A saved ticket type remains removable when Halo's catalog is unavailable. The unknown ID is a simulated test value.

Contact and company auto-import

Contact auto-import: turn on Contact Auto-Import to create user accounts for active contacts when companies are added, and select a Default Role for Imported Contacts (e.g., Viewer). Optionally, under Portal roles by Halo role, select Add rule to give a Halo role or the Important Contact flag another portal role. When a contact matches more than one rule, the rule highest in the list wins. Contacts that match no rule get the default role. To create portal users from your clients’ Microsoft 365 tenants instead, use an access rule with the action Import Microsoft 365 users (branch preview). See Set access rules.
Company auto-import: under Auto-Import Company Types, select the Halo client types to create in the portal automatically during sync. MSPortal asks you to confirm before it imports a new batch, because companies are a billed item.

Auto-import to Planner

With Enable Opportunity Sync on, the Auto-import to Planner switch sits below the Extended data switches and controls which opportunities create planner items:

Setting	Description
Auto-import to Planner	Master switch. When off, opportunities only come into the planner via the manual Import Opportunities dialog. Turning it on reveals the two filters below.
Minimum opportunity value	Skip opportunities below a value threshold (useful for filtering out noise from small stub deals)
Opportunity types to auto-import	Halo opportunity types to include. The list comes from the opportunity types that have appeared in your Halo data, since Halo’s opportunity type is free text. If none are selected, all types are eligible.

Once enabled, every Halo sync creates planner items for new matching opportunities and keeps existing PSA-managed planner items in sync. See Importing PSA Opportunities in the Planner guide. Hide invoice statuses chooses which invoices appear on the Invoices page. Hiding a status does not stop those invoices from synchronizing. Synchronizing source records, linking them to companies and importing portal records are separate steps. Use the initial-sync action when offered, then inspect the result. Options in later tasks may stay incomplete while background work runs, so check errors and sync results before treating an empty list as the final dataset.

Import or match companies and users

Open Import or match companies. Its first view, Import, includes unlinked records with or without suggestions; Suggested is available for reviewing proposed matches. Use the Import action beside a source company for a single import, or Import companies to open the selection dialog. The dialog loads unmatched records across provider pages for the current search. Use Select current page for its displayed page or Select all pages for every matching record. Review the names and selected count, then confirm the import. Existing portal companies with the same name are matched instead of duplicated. To link a company that already exists under a different name, choose it in the row or review and accept the suggested match. Accepted matches, unlinking and ignores save when applied; opening the import dialog alone saves nothing. Import or match at least one company, then open Import or match users for its contacts. You can leave other companies for later and return to import more users. The workspace opens on Import, which includes suggested contacts too. Use Import beside a contact, or select contacts and choose Import selected. Use the header checkbox to select the current page, click it again to select all pages matching the current filters, and click again to clear the selection. Select all with email replaces the selection with contacts that have an email address across all pages matching the current filters. Large selections run in batches. In the review panel, choose the intended Company role and review the ready-to-import and skipped counts. Contacts without an email address are skipped; you can optionally add an address before confirming. Correct invalid addresses or clear them to skip those contacts, and resolve duplicate addresses. To link an existing account, choose that user or accept a reviewed suggestion. Importing contacts does not automatically invite them to the portal. Review name-only suggestions carefully. You can ignore contacts you do not intend to import and restore them later. See Import companies and Import users for selection scope and retry guidance.

Halo PSA contact imports inside Launch Center with row Import actions and page selection controls — MSPortal Demo: the Halo Import or match users task embedded in Launch Center.

Import devices

Use the optional Import devices task to bring Halo assets into MSPortal as devices. Make sure Enable asset sync is on in Choose data, then map Halo asset types to MSPortal device types and select the assets to import. Check existing records before creating duplicates. See Import Devices for the full guide.

Configure tickets

Configure tickets sets ticket behavior inside MSPortal. Choose the relevant teams in Choose data first; the status lists stay empty until you do. Selectors save immediately and text fields save after editing or when you continue. Wait for the saved state before you leave.

Ticket Defaults sets the PSA values used for new tickets created in the portal. These are the same defaults as Settings > Tickets, and editing them requires the Ticket Settings permission. It includes the Requester field, which records each submitter’s name in a ticket UDF. See Requester field. Add that UDF to your Halo ticket types, or Halo drops the value.
Closed Statuses marks the statuses that mean a ticket is closed, and Client Comment Status is the status set when a client comments on a ticket (e.g., “Updated”).
The Resolution Status Stepper shows ticket progress. Map your Halo statuses to each stage: New, Triaged, Working, Waiting and Resolved. You can map several statuses to one stage.
Quick Sync requests an immediate ticket sync. Clear & Resync clears portal ticket data for this connection and reads the last 365 days of tickets from Halo again. Use it only for an intended rebuild, and see Clear and Resync Integrations first.

Once you turn on Settings > Tickets > General > Email ticket notes, staff and company users can add contacts or any email address in Email to on a public ticket note. Halo sends the note to them from your Halo mailbox, so replies thread back into the ticket. Halo needs no reply mailbox in MSPortal.

Configure opportunities

Configure opportunities sets the values used for opportunities created from MSPortal. Halo requires several fields on every opportunity, so these defaults let the planner Create Opportunity action post a complete opportunity to Halo without prompting each time.

Setting	Description
Default Workflow	The Halo workflow new opportunities are placed into
Default Conversion Probability	Starting probability percentage
Default Categories (Category 1 - 4)	Halo’s four category fields, each picked from your Halo instance. Required if your Halo instance marks any category as mandatory for opportunities.

Use Linked planner item refresh to choose which planner fields each sync updates. When the planner posts a new opportunity, Halo errors (missing Category 4, validation failures) appear in the planner instead of failing silently.

Review and finish setup

Open Review, resolve any remaining required tasks and select Finish setup. Completion does not mean every background import or sync has succeeded; check the results and client visibility separately. Saved changes remain when you leave; reopen the connection and select a task to continue.

Maintain the connection

Use Overview and Sync activity to inspect connection status and synchronization. Run sync in the connection header starts a sync of all data or one dataset, and More actions holds the other connection actions. To rotate credentials, open Connect, enter the new values, select Test connection, then Save changes. A successful test alone does not save the replacement. Changing the Halo URL requires entering the client secret again. To remove the integration, open More actions and choose Disconnect…. The confirmation lists the stored credentials, matches and synced data that will be removed. Delete the API application in Halo separately. Once your integration is configured, you can:

View synced tickets in the Tickets module
Access customer data in the Companies module
Create opportunities from the Planner module
Link projects to planner items

Show Halo assets as agreements

You can show assets of chosen Halo asset types as agreements, such as software licences or domain renewals. This works without device asset sync, but the Halo API application needs read access to assets.

Open Choose data

Open Settings > Integrations, open the Halo PSA connection and choose Choose data.

Pick the asset types

Under Agreements from assets, select the types in Asset types shown as agreements.

Map the fields

For each type, choose the Halo asset fields for Agreement name, Start date, End or renewal date and Value. Agreement name defaults to Asset name in Halo. Each choice saves at once.

Each active asset of a chosen type appears on Agreements under its linked company, with a Halo asset badge. Inactive assets drop out. See Find and review an agreement.

Sync company fields and alerts from HaloPSA

Company custom fields can follow a HaloPSA customer field or the customer’s pop-up notes. In Settings > Customization > Fields > Companies, edit a text field and choose the source in Sync from HaloPSA. Synced values are read-only in MSPortal and update with each HaloPSA company sync. Turn on Show as alert to show the value as a banner on the company’s pages; the account manager gets a notification when HaloPSA changes it. See Company fields from HaloPSA and alerts.

Import HaloPSA native CSAT for dashboards and reports

This imports satisfaction feedback already collected in Halo PSA. You do not need Simplesat or a new MSPortal survey, and you can keep using Halo’s own satisfaction survey. The import is off by default.

Grant feedback read access

In Halo, give the MSPortal.ai API application the read:feedback permission (or the all scope).

Re-check permissions

In MSPortal, open the Halo PSA connection, choose Permissions, click Re-check and confirm Satisfaction feedback is granted.

Turn on the import

Open Choose data and turn on Import satisfaction ratings.

Set the rating scale

Set Rating scale to match the survey configured in Halo: 1 to 3, 1 to 4, 1 to 5 or 1 to 10. The default is 1 to 5. Halo sends the score without the scale, so the wrong scale changes every CSAT percentage. If your Halo survey rates its best response lowest, such as 1 for excellent, turn on Lowest score is best.

Wait for the import

The toggle and rating scale save immediately. Imports then run hourly; saving is not proof that all responses have arrived.

Check company links

Make sure the feedback’s tickets have synced and their companies are linked to portal companies. A response whose ticket or company cannot be resolved yet will not appear in company-scoped CSAT results until a later sync resolves it.

Grant read access

Give intended readers Surveys > Read > CSAT in their role. Building dashboards and reports also needs the matching permissions.

Present the imported feedback

Where	How
CSAT Dashboard	Open Surveys > CSAT Dashboard to read scores, trends and feedback, or export responses. Halo feedback is grouped under Halo PSA satisfaction. See Read and export support satisfaction feedback.
Custom dashboards	Add CSAT Overview, CSAT Trend, CSAT by Company or Recent CSAT Feedback from the widget library, then save the dashboard. See Create and edit a dashboard.
Reports	Use the same CSAT blocks in the report builder, select the company and reporting period, and save. See Reporting.

These CSAT views can include other connected feedback sources alongside Halo. Check the company selection, dates and survey filter before you read a total as Halo-only. Technician statistics depend on the ticket’s technician mapping.

If Halo CSAT is missing

Connecting Halo does not turn on the import by itself. Check that Import satisfaction ratings is saved, Satisfaction feedback is granted, the last import succeeded in Sync activity, the rating scale and Lowest score is best setting are right, the tickets have synced, the companies are linked, the selected dates are right and the reader has the CSAT permission. If the Import satisfaction ratings toggle does not appear at all, contact MSPortal support. If most of your technicians show unexpectedly low CSAT, check the survey direction first. Read a few imported comments: praise attached to low scores means Lowest score is best should be on.

Devices from Halo assets

MSPortal treats an RMM, MDM or network tool as the source of truth for a device. When an RMM is connected, a Halo asset keeps or creates a device only when its type has Auto-import on and is not ignored in Import Devices. Assets of other types add their details to devices your RMM reports.

Assets removed in Halo. Every asset sync reads the full asset list from Halo. MSPortal only acts on a list it read to the end. An asset deleted or marked inactive in Halo is removed from staging three days later, and stays if it comes back or is reactivated in the meantime. An asset with an excluded status, or in a company no longer mapped, stops syncing and keeps its device.
What happens to the device. When the asset leaves staging, its device moves to another integration that still reports it, such as your RMM. A device nothing else reports is removed. In a tenant with an RMM, an IT Glue or other PSA record keeps the device only when its type has Auto-import on.

Only companies still mapped to this connection are affected, and archived devices are never removed.

Troubleshooting

Issue	Solution
Connection test fails	Verify your Halo URL, Client ID, and Client Secret are correct. Ensure `app.msportal.ai` is in the CORS whitelist.
A data option is unavailable	Check its result in Permissions, grant the named Halo permission and select Re-check.
Tickets not syncing	Check that the correct teams are selected in Ticket Sync Scope, that ticket statuses and types aren’t excluded, and that the API agent belongs to those teams.
New statuses are absent	Run a sync and check the selected teams in Choose data.
Contacts not importing	Verify Contact Auto-Import is on and a default role is selected in Choose data.
Permission errors	Review the API permissions in Halo PSA and ensure all required permissions are enabled. See Create Custom Halo PSA Role and API User.
Projects load, but creating or editing one fails	Check Project Modify on the application and the agent’s project access.
A project loads, but its child ticket, checklist or note cannot be changed	Check ticket write, action and to-do access, ticket type access and team or client restrictions on the API agent.
Logging project time fails	Check permission to add the time recording action, the agent mapping and billing options. The Time entries check only tests read access.
Setup finished but records are absent	Check pending imports, errors in Sync activity and the selected company.
Halo satisfaction feedback is missing from CSAT views	Check the saved Import satisfaction ratings toggle, `read:feedback`, the rating scale, company links and the reader’s CSAT permission.

Frequently asked questions

Can I dashboard or report on HaloPSA native CSAT responses?

Yes. Turn on Import satisfaction ratings in the Halo connection’s Choose data task, grant feedback read access, and choose the correct rating scale. Imported responses are available in the CSAT Dashboard, custom dashboard CSAT widgets, report blocks and CSV exports, subject to company mapping and role access. You can keep using Halo’s own survey; Simplesat is not required.

Does Test connection only test credentials?

Yes. After a successful test, use Save and continue for a new connection or Save changes for an existing one. Launch Center uses its Continue control to save and advance.

Does a green permissions result verify ticket writes?

No. The permission checks probe read access. Creating tickets, comments or other vendor changes needs the relevant write permission and a successful action.

Does Finish setup mean all data is ready?

No. Check the background sync result and verify company, user and device imports separately.

Will every discovered contact receive portal access?

No. Discovery and import are separate. Review user matches, company links and the permissions assigned to portal users; invitation is a separate workflow.

Can I replace saved credentials by retesting the form?

Retesting verifies the entered values. Select Save changes and wait for success before revoking the old vendor credential.
